輸出電壓OUTPUT（V）
|
4.2----7
|
7.1----11
|
11.1----17
|
17.1----24
|
24.1----36
|
|
輸出電流OUTPUT（A）
|
0.01----40
|
0.01----30
|
0.01----20
|
0.01----10
|
0.01----7
|
|
輸出功率OUTPUT（W）Max
|
200
|
200
|
240
|
250
|
250
|
|
輸入INPUT
|
|
電壓Voltage/頻率Hz
|
100V—240VAC 50-60Hz Through the switch
|
|
調整范圍Adjusting range
|
90V—264VAC，47Hz—63Hz Through the switch
|
|
保護Protection
|
內置一次性保險絲不可拆卸Internal Primary Current Fuse, Inrush Limiting
|
|
輸出 OUTPUT
|
|
輸出電壓調整范圍OUTPUT VOLTAGE ADJ.
|
±2%
|
|
紋波Ripple
|
1～2%Vp-p Max
|
|
瞬態響應Transient Response
|
在50%負載時0.5毫秒 0.5mS for 50% Load Change Typical
|
|
過流保護點OCP
|
105%～150%
|
|
電性 Electrical
|
|
絕緣強度Dielectric Withstand
|
輸入—輸出INPUT—OUTPUT
|
1.5KVAC/min, Cutoff current＜5mA
|
|
輸入—地INPUT—FG
|
1.5KVAC/min, Cutoff current＜5mA
|
|
出—地OUTPUT—FG
|
0.5KVAC/min, Cutoff current＜5mA
|
|
轉換效率 Efficiency
|
＞80% typ
|
|
浪涌電流 surge current
|
當輸出為額定負載,環境溫度為25℃,輸入240VAC冷態起動電源時的最大浪涌電流小于30A，30A MPS@240VAC at 25 ℃ Cold start
|
|
絕緣等級Insulation class
|
輸入對地最小50兆歐 50M ohms minimum from input to ground
|
|
平均無故障時間 MTBF
|
在25℃環境溫度下，額定負載工作平均無故障時間30,000小時；In 25 environment Temp,The Rated load MTBF 30000H
|
|
接口類型interface type
|
9.5-7P
|
|
使用環境Environmental
|
|
工作溫度Operaturing Temperature
|
0℃～45℃
|
|
儲存溫度Storage Temperature
|
-20 to +80°C
|
|
相對濕度Relative Humidity
|
工作：20%～80%RH Operating 20 to 80% RH
|
|
儲存:10 - 90% RH Storage: 10 to 90% RH
|
|
冷卻方式Cooling
|
自然冷卻Natural Convection Cooling
|
